Wire Rope Slings
- Least expensive per capacity of all steel slings
- Good abrasion resistance increases useful life of sling
- IWRC can be used at temperatures up to 400° F
- Countless combinations of sling terminations to fit specific lift requirements
- Available in wire core for strength and fiber core for flexibility
- Numerous body constructions for variety of applications
- Permaloc™ slings have reserve strength should the sleeve become damaged in use
Permaloc™ Wire Rope Slings
Lift-All Permaloc slings are made using the Flemish Eye splice technique to form the eyes. Unlike the simple return loop method that places 100% of its strength on the swaged sleeve, Permaloc slings have reserve strength should the sleeve become damaged in use.
Maintains all the basic Lift-All wire rope sling features plus...
Download our Permaloc™ Wire Rope Sling catalog Find a Distributor
Eye/Eye Style Slings
- Reserve strength: Integrity of eyes not solely dependent upon steel sleeves.
- When specified, thimble eyes protect wire rope from wear for increased life.
- Good abrasion resistance for longer life.
| Wire Rope Class | 6X19 EIPS IWRC | 6X37 EIPS IWRC | |||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Rope Dia. (in.) | 1/4 | 5/16 | 3/8 | 7/16 | 1/2 | 9/16 | 5/8 | 3/4 | 7/8 | 1 | 1-1/8 | 1-1/4 | 1-3/8 | 1-1/2 | 1-3/4 | 2 | 2-1/4 | 2-1/2 | |
| EIPS IWRC Rated Capacity* (tons) |
Vertical | .65 | 1.0 | 1.4 | 1.9 | 2.5 | 3.2 | 3.9 | 5.6 | 7.6 | 9.8 | 12 | 15 | 18 | 21 | 28 | 37 | 44 | 54 |
| Choker | .48 | .74 | 1.1 | 1.4 | 1.9 | 2.4 | 2.9 | 4.1 | 5.6 | 7.2 | 9.1 | 11 | 13 | 16 | 21 | 28 | 35 | 42 | |
| Vertical Basket |
1.3 | 2.0 | 2.9 | 3.9 | 5.1 | 6.4 | 7.8 | 11 | 15 | 20 | 24 | 30 | 36 | 42 | 57 | 73 | 89 | 109 | |
* Do not exceed rated capacities. Sling capacity decreases as the angle from horizontal decreases. Slings should not be used at angles of less than 30°. Refer to the Effect of Angle chart in the General Information section of our catalog.
Bridle Slings
- Alloy steel hardware assures long life.
- Bridles provide better load control and balance.
- Thimble eyes protect wire rope from wear for increased life.
- Easier rigging provided when hooking into fixed lifting points.
- Available in 2-leg, 3-leg, and 4-leg.
Endless Sling
- Made from one 6X19 or 6X37 EIPS IWRC wire rope, mechanically joined with steel sleeves.
- Wear points can be shifted to extend sling life.
- The most versatile style of sling - fewer slings to inventory.
| Endless - Mechanical Splice | |||
|---|---|---|---|
| Rope Dia. (in.) | Rated Capacity* (tons) | ||
| Vertical | Choker | Vertical Basket | |
| 1/4 | 1.0 | .71 | 2.0 |
| 5/16 | 1.6 | 1.1 | 3.1 |
| 3/8 | 2.3 | 1.6 | 4.5 |
| 7/16 | 3.1 | 2.1 | 6.1 |
| 1/2 | 3.9 | 2.8 | 7.9 |
| 9/16 | 5.0 | 3.5 | 10 |
| 5/8 | 6.1 | 4.3 | 12 |
| 3/4 | 8.8 | 6.2 | 18 |
| 7/8 | 12 | 8.3 | 24 |
| 1 | 15 | 11 | 31 |
* Do not exceed rated capacities. Sling capacity decreases as the angle from horizontal decreases. Slings should not be used at angles of less than 30°. Refer to the Effect of Angle chart in the General Information section of our catalog.
Download our Endless Slings catalog Find a Distributor
E-Z Flex™ Cable Laid Slings
E-Z Flex slings are made from a machine laid rope that consists of seven individual, galvanized ropes.
Download our E-Z Flex™ Cable Laid Slings catalog Find a Distributor
Eye/Eye Style Slings
- Superior flexibility - resists damage from kinking.
- Galvanized coating for corrosion resistance and longer life.
- 8 standard eye combinations.
- Available in 7x7x7 and 7x7x19
| Rope Dia (in.) | Rated Capacity8 (tons) | |||
|---|---|---|---|---|
| Vertical | Choker | Vertical Basket | ||
| 7x7x7 | 1/4 | .50 | .34 | 1.0 |
| 3/8 | 1.1 | .74 | 2.2 | |
| 1/2 | 1.9 | 1.3 | 3.7 | |
| 5/8 | 2.8 | 1.9 | 5.5 | |
| 7x7x19 | 3/4 | 4.1 | 2.8 | 8.1 |
| 7/8 | 5.4 | 3.7 | 11 | |
| 1 | 6.9 | 4.7 | 14 | |
| 1-1/8 | 8.3 | 5.8 | 17 | |
| 1-1/4 | 9.9 | 7.0 | 20 | |
| 1-1/2 | 13 | 9.1 | 26 | |
* Do not exceed rated capacities. Sling capacity decreases as the angle from horizontal decreases. Slings should not be used at angles of less than 30°. Refer to the Effect of Angle chart in the General Information section of our catalog.
2 Leg Bridle Slings
- Bridles provide better load control and balance.
- Sliding choker hook speeds rigging of bundled materials.
- Galvanized coating for corrosion resistance and longer life.
Endless Sling
- Load stability and balance achieved by spreading sling legs in basket and choker hitches.
- Smaller rope diameter per capacity increases flexibility.
- More flexible than eye slings of comparable strength.
| E-Z Flex Endless Sling | ||||
|---|---|---|---|---|
| Rope Dia. (in.) | Vertical | Choker | Vertical Basket | |
| 7x7x7 | 1/4 | .83 | .54 | 1.7 |
| 3/8 | 1.8 | 1.2 | 3.6 | |
| 1/2 | 3.0 | 2.0 | 6.1 | |
| 5/8 | 4.6 | 3.0 | 9.1 | |
| 7x7x19 | 3/4 | 6.7 | 4.3 | 13 |
| 7/8 | 8.9 | 5.8 | 18 | |
| 1 | 11 | 7.3 | 23 | |
* Do not exceed rated capacities. Sling capacity decreases as the angle from horizontal decreases. Slings should not be used at angles of less than 30°. Refer to the Effect of Angle chart in the General Information section of our catalog.
